Schneider Electric 9001SKR9P35RH13 Push-button Switch

Product Description

The SCHNEIDER ELECTRIC 9001SKR9P35RH13 is a maintained-action push-button switch rated for 28 volts, designed for industrial and commercial control panel applications. It features a 30 mm mounting hole diameter, an extended straight actuator in red, and a dual NC/NO contact configuration. This switch holds its position after actuation rather than springing back, making it suitable for on/off control functions where a latched state is required. Licensed electricians and industrial control technicians are the primary installers for this type of device.

This push-button switch is intended for use in control panels, operator stations, and machine interfaces where a maintained-contact, 30 mm format device is needed. The red extended actuator provides clear visual identification for stop, shutoff, or alert functions in typical industrial wiring applications. Its NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 ratings make it suitable for environments ranging from general indoor use through watertight and corrosion-resistant installations.

Key Features

• Maintained (MA) operation — switch holds position after each press
• Dual NC/NO contact configuration for flexible wiring options
• 30 mm mounting hole diameter fits standard 30 mm control panel cutouts
• Red extended straight actuator for high-visibility operator identification
• NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 rated for broad environmental suitability
• Rated at 28 volts for low-voltage control circuit use

Compatibility

Designed as an OEM-style replacement or direct-fit component for 30 mm push-button operator stations and control panel assemblies requiring a maintained-action switch with NC/NO contacts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out the control panel before removing or installing the switch. Verify that the panel cutout diameter matches the 30 mm mounting specification before mounting. Confirm contact configuration wiring against the control circuit diagram prior to restoring power.
