Schneider Electric 9001SKR9P1RH13 Push-button Switch

Product Description

The SCHNEIDER ELECTRIC 9001SKR9P1RH13 is a maintained-action push-button switch designed for industrial and commercial control panel applications. Rated at 120 volts AC, it features a 30 mm mounting hole diameter and an extended straight red push button. The NC/NO contact configuration makes it suitable for both normally closed and normally open control circuits. Its NEMA 4X rating among its multirating supports use in wet, dusty, and corrosive environments. Licensed electricians and industrial maintenance technicians typically install this switch as part of machine control, motor starter, or operator interface assemblies.

This switch fits 30 mm industry-standard panel cutouts, making it compatible with common control enclosures and operator stations. The maintained operation type means the button stays in its actuated position until pressed again, which suits applications like run/stop control, on/off selector logic, or two-state signaling in machinery, HVAC air handling units, and process equipment. The red extended actuator provides clear visual identification for stop or emergency-type functions in a panel layout.

Key Features

• Maintained (MA) operation holds actuated position until next press
• NC/NO contact configuration supports both normally closed and normally open circuits
• Extended straight red push button provides high visibility in control panels
• 30 mm mounting hole diameter fits standard industrial panel cutouts
• NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 rated for broad environmental coverage
• Compact form factor at 4.4 x 2.2 x 1.8 inches and 0.47 pounds

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for industrial control panels and operator stations using a standard 30 mm mounting hole diameter.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lockout/tagout the control panel before mounting or wiring this switch. Verify that the supply voltage matches the 120 volt AC rating before applying power. Confirm contact configuration wiring against the circuit schematic to ensure proper NC or NO circuit behavior.
