Schneider Electric 9001SKR9P1 Push-button Switch 120V Ac

Product Description

The SCHNEIDER ELECTRIC 9001SKR9P1 is a maintained-action push-button switch rated for 120 volts AC and designed for industrial and commercial control panel applications. With a 30 mm mounting hole diameter and an extended straight push-button style, this switch provides reliable operator interface control in demanding environments. The maintained operation type means the switch holds its actuated state until manually reset, making it suitable for on/off control functions where a latched output is required. Licensed electricians and industrial control technicians are the primary installers of this switch type.

This push-button switch is built for use in control enclosures, machine panels, and operator stations across light industrial, commercial, and HVAC control applications. The NEMA ratings cover a broad range of enclosure types including NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13, making the 9001SKR9P1 suitable for both indoor dry locations and wet or wash-down environments. It fits standard 30 mm cutout panels and can serve as a direct replacement component in existing control assemblies requiring a maintained push-button actuator at 120 volts AC.

Key Features

• Maintained (MA) operation holds switch state after actuation until manually reset
• Extended straight push-button style for clear operator interface visibility
• 30 mm mounting hole diameter fits standard industrial panel cutouts
• 120 volts AC rating suits common North American control circuit voltages
• NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 ratings cover a wide range of enclosure environments

Compatibility

Designed as an OEM-style replacement push-button switch for 30 mm industrial control panel assemblies requiring a maintained-action actuator at 120 volts AC.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before removing any existing switch or making wiring connections. Verify the panel cutout is clean and matches the 30 mm mounting hole diameter before seating the switch body. Confirm the circuit voltage matches the 120 volt AC rating of this switch prior to re-energizing the panel.
