Schneider Electric 9001SKP38LYA9 Led Pilot Light 120V

Product Description

The SCHNEIDER ELECTRIC 9001SKP38LYA9 is a 120-volt AC LED pilot light designed for panel and control enclosure applications. It features a round white lens and a screw clamp connector for secure, tool-assisted termination. The LED lamp type delivers long service life and low heat output compared to incandescent alternatives. At 3.7 inches in overall length and 2.4 inches wide, the unit fits standard 30mm cutout mounting configurations. Weighing 0.5 pounds, it is built for vibration-resistant service, making it suitable for machine tool panels, pump control stations, and industrial automation enclosures. Licensed electricians and control panel builders are the typical installers.

This pilot light is intended for use in commercial and industrial control panel assemblies where a visual status indicator is required. Its vibration-resistant construction suits environments with continuous mechanical activity such as compressor rooms, pump stations, and conveyor control panels. The 120-volt AC operating voltage matches standard North American control circuit voltages. The screw clamp connector supports fast, reliable field wiring without soldering. It is rated for use in NEMA 1, 2, 3, 3R, 4, 4X, 12, and 13 enclosure environments, covering both indoor and outdoor weatherproof applications.

Key Features

• LED lamp type for extended service life and reduced heat generation
• 120-volt AC operating voltage matches standard North American control circuits
• Round white lens for clear, unambiguous status indication
• Screw clamp connector for secure, tool-terminated field wiring
• Vibration-resistant construction rated for demanding industrial environments
• NEMA 1, 2, 3, 3R, 4, 4X, 12, and 13 enclosure ratings for broad application coverage

Compatibility

Rated for installation in NEMA 1, 2, 3, 3R, 4, 4X, 12, and 13 enclosures. Meets CSA C22.2 No. 14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C 4520, JIS C 852, UL 508, and related standards. Designed as an OEM-style replacement or new-installation pilot light for 120-volt AC industrial control panels.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before beginning any wiring work. The screw clamp connector requires a small flat-blade screwdriver for termination. Verify the panel cutout dimensions and enclosure NEMA rating match the requirements of the application before mounting.
