Schneider Electric 9001SKP35LRR9 Led Pilot Light 24V

Product Description

The SCHNEIDER ELECTRIC 9001SKP35LRR9 is a 24V AC/DC LED pilot light designed for panel-mount indicator applications in industrial and commercial control systems. It features a red round lens and uses an LED lamp type for long service life and low power draw compared to incandescent alternatives. The screw clamp connector simplifies field wiring, and the unit is rated vibration resistant, making it suitable for equipment subject to mechanical vibration. At 3.7 inches in length, 2.4 inches wide, and 2 inches in height, this pilot light fits standard 30mm operator cutouts and meets a broad range of international standards. Licensed electricians and panel builders are the typical installers.

This pilot light is used in industrial control panels, machine tool enclosures, and commercial electrical equipment where a reliable 24-volt AC or DC status indicator is required. The red lens provides a clear visual signal for fault, stop, or power-on indication depending on panel design. Its compliance with NEMA 1, 2, 3, 3R, 4, 4X, 12, and 13 enclosure ratings means it can be specified across a wide range of indoor and outdoor panel environments. It is equally suited to new panel builds and replacement of worn or failed pilot lights on existing equipment.

Key Features

• LED lamp type for extended service life and reduced maintenance
• Operates on 24V AC or 24V DC supply voltage
• Red round lens for clear status indication
• Screw clamp connector for secure, tool-assisted field wiring
• Vibration resistant construction for use on machinery and industrial equipment
• Meets NEMA 1/2/3/3R/4/4X/12/13 enclosure ratings and multiple UL, CSA, EN/IEC, and JIS standards

Compatibility

Designed as an OEM-style replacement or new-installation pilot light for 30mm operator cutout industrial control panels rated for 24V AC or DC circuits.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before mounting or wiring this pilot light. The screw clamp terminals require a small flathead screwdriver for proper termination. Verify supply voltage matches the 24V AC/DC rating of this unit before energizing the panel.
