Schneider Electric 9001SKP1A9 Pilot Light 120V White

Product Description

The SCHNEIDER ELECTRIC 9001SKP1A9 is an incandescent pilot light designed for industrial control panel applications operating at 120 volts AC. It features a white round lens and a screw clamp electrical connection, making field installation straightforward without specialized tooling. Built for demanding environments, the unit is vibration-resistant, supporting reliable indicator function in machinery and equipment subject to continuous motion or shock. The overall diameter measures 1.65 inches with a panel cutout requirement of 1.18 inches, and the unit weighs 0.37 pounds. Electricians and panel builders install this type of indicator light to provide clear visual status signals on motor control centers, machine panels, and similar equipment.

This pilot light is suited for residential and commercial control panel installations where a 120V AC incandescent status indicator is required. Typical applications include motor starters, HVAC control panels, pump control stations, and industrial machine operator interfaces. The screw clamp connector accommodates standard control wiring practices and the round lens format fits standard 30mm panel cutouts common in NEMA-rated enclosures.

Key Features

• 120 volts AC incandescent lamp for standard control circuit voltage compatibility
• White round lens for clear, unambiguous status indication
• Screw clamp connector for secure, tool-assisted wire termination
• Vibration-resistant construction for use in machinery and motion environments
• Fits 30mm panel cutout — compatible with widely used NEMA enclosure configurations
• Meets multiple standards including UL 508, CSA C22.2 No. 14, NEMA 1/2/3/3R/4/4X/12/13, and EN/IEC 60947 series

Compatibility

Designed as an OEM-style replacement or new-installation pilot light for 30mm panel cutout positions in NEMA-rated industrial and commercial control enclosures operating at 120V AC.

Installation Notes

Installation is performed by a licensed electrician or qualified panel builder. De-energize and lock out the control panel before removing or installing the pilot light, following NFPA 70E lockout/tagout procedures. Secure the screw clamp connections to the control circuit wiring and verify the panel cutout diameter is 30mm before mounting. Do not exceed the rated 120V AC supply voltage for this device.
