Schneider Electric 9001SK1L1GH13 Square D 600 VAC Momentary 30 mm Push Button

Product Description

The Schneider Electric 9001SK1L1GH13 is a modular illuminated flush green push button with a plastic bezel. It features a full guard arrangement, making it an effective control interface for machines. The product is designed for installation into standard thirty millimeter diameter panel cut-outs and connects to control circuits via screw-clamp connections.

• Impact resistant, dust and water resistant rated to IP66
• Includes a 110 Volt AC transformer
• Supports one normally open and one normally closed contact

Product Highlights

This illuminated push button is easy to spot at a distance due to its bright color and illuminated head, suitable for use in various industrial settings.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Product Type: Illuminated push-button
• Size: 1.18 inches
• Voltage: 110 to 120 Volt AC 50/60 Hz
• Weight: 0.40 pound
• Environmental Conditions: Water tight, dust tight, oil tight
• Operating Temperature: -25 to 70 degrees Celsius
• Contact Rating: AC15 - DC13
• Country of Origin: Mexico
