Schneider Electric 9001SK11J1G Selector Switch 2 Position

Product Description

The SCHNEIDER ELECTRIC 9001SK11J1G is a 2-position maintained selector switch with a green knob operator designed for panel-mount industrial control applications. Built with a plastic bezel in black and rated for a 1.18-inch (30 mm) mounting hole, this switch holds its selected position until manually moved — no spring return. It carries UL, CSA, and CE certifications and meets NEMA ratings 1, 2, 3, 3R, 4, 4X, 6, 12, and 13, making it suitable for demanding environments where dust, oil, moisture, and corrosion resistance are required. Electricians and industrial control technicians install this switch as a stand-alone operator head; contact blocks are ordered separately.

This selector switch is used in industrial and commercial control panels where a two-state, maintained switching operation is needed — such as hand/off, on/off, or local/remote control circuits. Its NEMA 4X and 6 ratings allow use in washdown, outdoor, and submersion-rated enclosures. The 30 mm panel cutout is a widely adopted industry standard, making this operator compatible with a broad range of enclosure types. It is typically installed by licensed electricians or industrial maintenance technicians in motor control centers, machine control panels, and process control stations.

Key Features

• Maintained (MA) operation — holds position until manually actuated again
• Green knob operator with black plastic bezel for clear visual identification
• 30 mm panel cutout diameter fits standard industrial enclosure knockouts
• NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 rated — suitable for indoor, outdoor, and washdown environments
• Anti-corrosive, dust-resistant, oil-resistant, and weatherproof construction
• UL Listed (File E42259, CCN NKCR), CSA LR24590 Class 3211 03, and CE certified
• Selector switch operator head only — contact blocks sold separately

Compatibility

Designed as an OEM-style panel-mount selector switch operator for 30 mm industrial control panel cutouts. No specific compatible model numbers were provided in the product data.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the control panel and verify zero voltage with a meter before beginning work. The operator head mounts through a 30 mm panel cutout and secures from the rear; contact blocks must be ordered and assembled separately before the switch is functional. Confirm the NEMA enclosure rating of the panel matches or is compatible with the switch rating for the installation environment.
