Schneider Electric 9001KT38LRR9 Led Indicating Light 120V

Product Description

The SCHNEIDER ELECTRIC 9001KT38LRR9 is a 120 VAC LED indicating light fitted with a red lens and screw clamp connector. It is designed for panel-mount status indication in industrial and commercial control enclosures. The LED lamp type provides long service life and low power draw compared to incandescent alternatives. At 4.5 inches in length, 2.3 inches wide, and 2 inches in height, it fits standard pilot light cutouts and mounts directly into control panels, motor starters, and push-button stations. Electricians and control panel builders install this unit as a run, fault, or power indicator in low-voltage and line-voltage circuits.

This indicating light is suited for residential, commercial, and light industrial control panel applications where a clearly visible 120 VAC status indicator is required. The red lens provides a standard fault or energized indication in panel assemblies, machine control enclosures, and operator interface stations. The screw clamp connector simplifies field wiring and allows secure termination without crimped ferrules. It is packaged individually and intended for single-unit replacement or new-build panel installations.

Key Features

• 120 VAC operating voltage for direct line-voltage indication circuits
• LED lamp type for extended service life and reduced maintenance
• Red lens for standard fault, power, or run status indication
• Screw clamp connector for secure, tool-assisted field wiring termination
• Compact footprint: 4.5 inches long, 2.3 inches wide, 2 inches tall
• Meets CE, CSA, NEMA, and UL listing requirements for use in multiple enclosure types

Compatibility

Designed as an OEM-style replacement or new-installation indicating light for 120 VAC industrial and commercial control panel assemblies using standard pilot light mounting configurations.

Installation Notes

Installation is performed by a licensed electrician or qualified control panel technician. De-energize and lock out the panel or enclosure before removing or installing the indicating light in accordance with NFPA 70E electrical safety procedures. Screw clamp terminations should be tightened with an appropriate flat-blade screwdriver to the connector manufacturer specification. Verify the supply voltage matches the 120 VAC rating of this unit before energizing.
