Schneider Electric 9001KT38 Indicating Light 120V

Product Description

The SCHNEIDER ELECTRIC 9001KT38 is a 120 VAC indicating light designed for industrial and commercial control panel applications. It uses a screw clamp connector for secure, vibration-resistant wiring termination. The unit measures 4.5 inches in length, 2.3 inches in width, and 2 inches in height, making it a compact fit for standard enclosure cutouts. Electricians and panel builders install this type of pilot light to provide visual status indication for machine control circuits, motor starters, and automated equipment. It carries UL, CSA, CE, and NEMA ratings, confirming suitability for a wide range of industrial environments.

This indicating light is suited for use in NEMA-rated enclosures across residential, commercial, and light industrial control panel installations. The NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 ratings make it appropriate for indoor dry locations as well as outdoor and wash-down environments where moisture or dust ingress is a concern. It is commonly installed on operator interface panels, machine control stations, and motor control centers where a clear visual run, fault, or power indication is required.

Key Features

• 120 VAC operating voltage for direct connection to standard control circuit power
• Screw clamp connector for reliable, tool-secured wire termination
• Compact footprint: 4.5 inches x 2.3 inches x 2 inches
• NEMA 1/2/3/3R/4/6/12/13 rated for broad environmental suitability
• UL Listed (File E42259, CCN NKCR) and CSA certified (LR25490 Class 3211 03)
• CE marked for compliance with applicable European directives

Compatibility

Designed as an OEM-style replacement indicating light for industrial control panels and operator stations requiring a 120 VAC pilot light with screw clamp termination.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lockout/tagout the control panel before installing or replacing the indicating light. Screw clamp terminals require a small flat-blade screwdriver for proper wire seating. Verify the supply voltage matches the 120 VAC rating of the device before energizing the circuit.
