Schneider Electric 9001KT1R31 Indicating Light Red Lens

Product Description

The SCHNEIDER ELECTRIC 9001KT1R31 is a red lens press-to-test indicating light with a screw clamp connector, designed for use in industrial and commercial control panel applications. The press-to-test function allows technicians to verify lamp operation without energizing the circuit, reducing diagnostic time during commissioning and routine maintenance. Built to meet NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosure ratings, this indicator is suitable for environments ranging from general indoor use to washdown and submersion-rated installations. It carries UL listing and CSA certification, making it compliant for use in both U.S. and Canadian electrical installations.

This indicating light is used in motor control centers, machine control panels, and automation enclosures where a pilot light is needed to signal circuit status, equipment state, or fault conditions. The red lens color is the industry standard for indicating fault, stop, or energized status. The screw clamp connector simplifies field wiring and reduces termination time compared to traditional screw terminal styles. Suitable for residential, commercial, and light industrial control applications where a reliable, code-compliant pilot light is required.

Key Features

• Press-to-test function for quick lamp verification without energizing the circuit
• Red lens for standard fault, stop, or energized status indication
• Screw clamp connector for secure, fast field wiring termination
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 rated for wide environmental suitability
• UL Listed (File E42259, CCN NKCR) and CSA certified (LR25490 Class 3211 03)
• CE marked for international compliance

Compatibility

Designed as an OEM-style replacement or direct-fit pilot light for industrial control panels and motor control enclosures requiring a NEMA-rated press-to-test indicating light with screw clamp termination.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lockout/tagout the control panel before removing or installing the indicator. Verify that the supply voltage matches the lamp rating before connecting. Screw clamp terminals should be tightened to the connector manufacturer's specified range using an appropriate flat-blade screwdriver.
