Schneider Electric 9001KT1LGG31 Led Pilot Light 120V Green

Product Description

The SCHNEIDER ELECTRIC 9001KT1LGG31 is a 120 VAC LED pilot light designed for industrial and commercial control panel applications. It features a round green lens and a screw clamp connector for secure, reliable termination. The LED lamp type provides long service life and low power draw compared to traditional incandescent pilot devices. This unit meets a broad set of international and North American standards, making it suitable for a wide range of control enclosure environments. Electricians and panel builders install this device as a status indicator in machine control, motor starter, and process control panels.

This pilot light is rated for use in NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosures, covering both indoor and outdoor applications as well as washdown and dust-tight environments. It is commonly installed on operator interface panels, control consoles, and motor control centers where a visual run or fault indication is required. The 120 VAC operating voltage matches standard North American control circuit voltages, making it a direct fit for most existing panel designs without additional transformers or resistors.

Key Features

• LED lamp type for extended service life and reduced maintenance
• Round green lens provides clear visual status indication
• Screw clamp connector for solid, vibration-resistant termination
• Rated for NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosures
• Meets UL 508, CSA C22.2 No. 14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C 4520, and JIS C 852 standards

Compatibility

Designed as an OEM-style replacement pilot light for industrial control panels and operator stations requiring a 120 VAC LED indicator with a round lens and screw clamp termination.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before mounting or wiring this pilot light. Use appropriately rated control wire and torque screw clamp terminals per panel wiring practices. Verify enclosure NEMA rating is compatible with the installation environment before installation.
