Schneider Electric 9001KS88K14 Selector Switch 4 Position

Product Description

The SCHNEIDER ELECTRIC 9001KS88K14 is a 4-position maintained selector switch designed for industrial control panel applications. It operates at up to 600 volts and uses a black knob operator with chrome metal bezel for durable, reliable actuation. The maintained action type holds its selected position until manually moved, making it suitable for multi-mode machine control, equipment sequencing, and process selection circuits. The 30 mm panel-mount hole diameter fits standard 30 mm cutout enclosures. This switch is installed by licensed electricians and industrial maintenance technicians working on motor control centers, machine panels, and automation equipment.

The 9001KS88K14 is rated for NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosures, covering a broad range of indoor and outdoor industrial environments including dust-resistant, oil-resistant, and weatherproof applications. It is well-suited for use in manufacturing facilities, process plants, and commercial mechanical rooms where reliable operator interface devices are required. The switch ships with zero contact blocks, allowing the installer to add the appropriate contact block configuration for the specific control circuit.

Key Features

• 4-position maintained operation for stable multi-mode control circuit switching
• 600V voltage rating for industrial control panel compatibility
• 30 mm panel mount hole diameter fits standard 30 mm operator cutouts
• Black knob operator with chrome metal bezel for clear visual identification
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 ratings cover dust, oil, and weather exposure
• CE, CSA, and UL Listed certifications for North American and international compliance

Compatibility

Designed as an OEM-style replacement or new-installation operator for standard 30 mm industrial control panel selector switch assemblies requiring a maintained 4-position knob operator.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before mounting or wiring. The switch requires a 30 mm round panel cutout and is panel-mounted using the included hardware or standard 30 mm operator mounting hardware. Contact blocks are not included and must be ordered separately to complete the switch assembly.
