Schneider Electric 9001KS46K10 Selector Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001KS46K10 is a 3-position maintained selector switch operator designed for panel-mount industrial control applications. It features a black knob operator with a chrome metal bezel and a 1.18-inch (30 mm) panel cutout diameter. Rated at 600 volts, this switch uses a maintained (MA) operation type, meaning it holds its selected position until manually moved. No contact blocks are included with this operator. It is built for environments requiring dust, oil, and weather resistance and carries CE, CSA, and UL listings. Licensed electricians and industrial controls technicians are the primary installers.

This selector switch operator is suited for panel-mount installations in residential, commercial, and light industrial control panels where a 3-position maintained selector is required. Typical applications include motor control circuits, machine tool panels, HVAC control systems, and other 600V-rated industrial or commercial electrical enclosures. The switch is compatible with NEMA-rated enclosures including Types 1, 2, 3, 3R, 4, 6, 12, and 13, making it appropriate for both indoor and outdoor or washdown-rated panel applications. The black knob operator provides clear tactile position feedback in multi-circuit control setups.

Key Features

• 3-position maintained (MA) operation — holds selected position without operator input
• 600V voltage rating suitable for industrial control panel applications
• Black knob operator with chrome metal bezel for durable, professional panel aesthetics
• 1.18-inch (30 mm) panel cutout diameter — standard 30 mm class mounting
• Dust-resistant, oil-resistant, and weatherproof construction
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosure ratings
• CE, CSA LR24590 Class 3211 03, and UL Listed (File E42259 CCN NKCR) certifications

Compatibility

Designed as an OEM-style operator for standard 30 mm class industrial selector switch assemblies. Compatible with NEMA Type 1, 2, 3, 3R, 4, 6, 12, and 13 rated enclosures. No contact blocks are included; contact blocks must be sourced separately and are not bundled with this operator unit.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out the control panel before installing or removing any switch operator. This unit requires a 1.18-inch panel cutout and panel-mount hardware appropriate for 30 mm class devices. Do not exceed the 600V rating of the switch operator when integrating into a control circuit.
