Schneider Electric 9001KS43K10 Selector Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001KS43K10 is a 3-position maintained selector switch operator designed for industrial control panel applications. This unit features a black knob-style operator with a chrome metal bezel and mounts through a 30 mm panel cutout. It operates at up to 600 volts and uses a maintained (MA) action, meaning the switch stays in the selected position until manually moved. The operator is sold without contact blocks, allowing technicians to configure the assembly with the appropriate contact block count for their specific control circuit. Rated for dust, oil, and weather resistance, it carries CE, CSA, and UL listings.

This selector switch operator is suited for residential and commercial control panels, machine tool enclosures, pump control stations, and similar industrial or HVAC control applications where a reliable, multi-position selector is required. The panel-mount design fits standard 30 mm operator holes and is appropriate for both new installations and replacement work in existing control panels. Electricians and industrial controls technicians are the primary installers. NEMA enclosure ratings of 1, 2, 3, 3R, 4, 6, 12, and 13 make it compatible with a wide range of indoor and outdoor enclosure types.

Key Features

• 3-position maintained (MA) operation — switch holds position without spring return
• Black knob operator with chrome metal bezel for durable, professional appearance
• 600-volt rating for use in standard industrial control circuits
• 30 mm panel mount hole diameter fits standard operator cutouts
• NEMA ratings 1, 2, 3, 3R, 4, 6, 12, and 13 — dust-resistant, oil-resistant, and weatherproof
• CE, CSA LR25490 Class 3211 03, and UL Listed (File E42259 CCN NKCR) certifications
• Sold as operator only — contact blocks ordered separately for custom circuit configuration

Compatibility

Designed as an OEM-style panel-mount selector switch operator for use in 30 mm industrial control panel assemblies across NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 rated enclosures.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before installing or replacing the operator. The unit mounts through a standard 30 mm panel hole and secures with the provided hardware. Because this part ships without contact blocks, verify the required contact block configuration before ordering to complete the switch assembly.
