Schneider Electric 9001KR9Y Push-button Switch 30mm Maintained

Product Description

The SCHNEIDER ELECTRIC 9001KR9Y is a maintained-action push-button switch designed for industrial control panel applications. It features a 30 mm mounting hole diameter and an extended straight yellow actuator that stays in position after each press, making it suitable for functions that require a latched on or off state rather than a momentary signal. The switch carries NEMA ratings of 1, 2, 3, 3R, 4, 6, 12, and 13, covering a broad range of environmental conditions from general indoor use to watertight and oil-resistant enclosures. Licensed electricians and industrial control technicians are the primary installers of this device.

This push-button switch is intended for use in industrial and commercial control panels, machine operator stations, and motor control centers where a maintained contact action is required. The yellow actuator color is commonly used to signal caution functions, fault reset, or specific process steps per established panel color-coding conventions. Its multi-NEMA rating makes it a practical choice for both indoor and outdoor enclosure applications where moisture or contaminant ingress protection is needed.

Key Features

• Maintained (MA) operation holds switch state after actuation without continuous operator force
• Extended straight actuator profile for positive operator engagement
• Yellow actuator color supports standard panel color-coding practices
• 30 mm mounting hole diameter fits standard 30 mm cutout operator stations
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 rated for wide environmental suitability

Compatibility

Designed as an OEM-style replacement or new-installation push-button operator for standard 30 mm industrial control panel cutouts.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before mounting or wiring the switch. The 30 mm mounting hole should be clean and deburred before inserting the operator body. Verify NEMA enclosure compatibility with the panel rating before completing the installation.
