Schneider Electric 9001KR9RH6S10 Push-button Switch

Product Description

The SCHNEIDER ELECTRIC 9001KR9RH6S10 is a maintained-action push-button switch rated for 600 volts and 10 amps, designed for industrial control panel applications. It features a red, round, extended mushroom-head operator with a chromium-plated metal bezel and a screw clamp terminal for secure wiring connections. The normally closed (NC) contact configuration means the circuit is closed at rest and opens when the button is actuated. This switch is installed by licensed electricians and control panel builders working on machine control, emergency stop, or process control circuits.

This switch is suited for industrial and commercial control panel installations where a maintained NC push-button is required. The 30 mm mounting hole diameter follows standard 30 mm panel cutout dimensions common across industrial control hardware. Its NEMA 13, 4, and 6 ratings make it appropriate for environments with exposure to dust, oil, water, and occasional washdown conditions. The non-illuminated mushroom head provides a clear tactile and visual indicator of actuated state without requiring a pilot light circuit.

Key Features

• Maintained (MA) operation with normally closed (NC) contact configuration
• Extended round mushroom-head operator in red with chromium-plated metal bezel
• 600-volt, 10-amp rating for industrial control circuit use
• Screw clamp terminal for reliable, tool-secured wiring connections
• NEMA 13, 4, and 6 rated enclosure compatibility for wet and oil-exposed environments
• UL Listed and CSA Certified for North American installations; CE Marked for international compliance

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for 30 mm industrial control panel cutouts requiring a maintained NC operator.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before mounting or wiring the switch. Secure field wiring to the screw clamp terminals using an appropriate screwdriver and confirm torque meets panel builder or enclosure manufacturer guidelines. Verify the contact configuration and maintained-action behavior match the control circuit logic before restoring power.
