Schneider Electric 9001KP5R31 Indicating Light 480V Red

Product Description

The SCHNEIDER ELECTRIC 9001KP5R31 is a 480-volt AC indicating light with a red lens and screw clamp connector, designed for use in industrial control panels and machine status signaling applications. The red lens provides a clear visual indicator for fault, stop, or alarm conditions on equipment. The screw clamp connector simplifies field wiring and reduces the risk of loose connections over time. This pilot light is built to meet multiple safety and environmental standards, making it a reliable choice for licensed electricians and industrial maintenance technicians working on control panel installations or replacements.

This indicating light is suited for use in residential, commercial, and light industrial control panel enclosures rated for NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 environments. The wide NEMA rating range makes it appropriate for both indoor dry locations and outdoor or wash-down-rated enclosures. Typical applications include motor control centers, machine control panels, and process equipment status boards where a 480-volt pilot light is required. Electricians and panel builders commonly specify this part for OEM control panel builds and field service replacements.

Key Features

• 480 VAC rated voltage with red lens for fault or stop status indication
• Screw clamp connector for secure, tool-assisted field wiring
• Rated for NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosure environments
• CE marked and UL Listed under File E42259 CCN NKCR
• CSA certified under LR25490 Class 3211 03
• Compact form factor suitable for standard pilot light cutouts

Compatibility

Designed as an OEM-style replacement indicating light for industrial control panels requiring a 480 VAC pilot light with a screw clamp termination. No specific model compatibility data was provided by the manufacturer for this listing.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the panel and verify the absence of voltage before removing or installing any pilot light component. Ensure the enclosure NEMA rating matches the installation environment before mounting. Torque the screw clamp terminals to the panel manufacturer or wire manufacturer specifications for the conductor size used.
