Schneider Electric 9001KP5G31 Indicating Light 480V Green

Product Description

The SCHNEIDER ELECTRIC 9001KP5G31 is a 480-volt green lens indicating light with a screw clamp connector, designed for panel-mounted status indication in industrial and commercial electrical systems. This pilot light provides a clear visual signal for equipment status, power presence, or circuit condition at 480 volts AC. The screw clamp connector simplifies field wiring and reduces termination time. At 0.5 pounds, the unit is compact and suited for installation in control panels, motor control centers, and operator interface stations. Licensed electricians and panel builders are the primary installers of this device.

The 9001KP5G31 is suited for use in industrial control panels, machine tool enclosures, and commercial electrical equipment where a 480 VAC green status indicator is required. The green lens convention typically signals a run, on, or normal operating condition. The screw clamp termination style supports solid and stranded conductors without the need for ferrules in most applications. This unit ships individually and is available as a single piece, making it a practical replacement or spare for existing panel assemblies.

Key Features

• 480 VAC rated for direct connection in high-voltage control circuits
• Green lens provides standard run or normal-status indication
• Screw clamp connector for secure, tool-assisted field wiring
• Compact form factor: 1.9 inches height, 2.2 inches width, 3.7 inches length
• Meets CE, CSA, NEMA, and UL listing requirements for broad application compliance

Compatibility

Designed as an OEM-style replacement or addition for industrial control panels and operator stations requiring a 480 VAC green pilot indicating light with screw clamp termination.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out the panel or control circuit before removing or installing any indicating light. Confirm the panel knockout or cutout diameter matches the unit body before mounting. Torque screw clamp terminals to the value specified on the panel schematic or conductor manufacturer guidelines.
