Schneider Electric 9001KP5 Indicating Light 480V

Product Description

The SCHNEIDER ELECTRIC 9001KP5 is a 480 VAC indicating light designed for use in industrial control panels and machine monitoring applications. It uses a screw clamp connector for reliable field wiring and provides a clear visual status indication for equipment operating at 480 volts. The unit measures 3.7 inches in length, 2.2 inches in width, and 2.0 inches in height, making it a compact fit for standard enclosure cutouts. Electricians and control panel builders install this type of pilot light to give operators a fast, unambiguous read on circuit or machine status.

This indicating light is suited for industrial and commercial control applications where a durable, standards-compliant pilot device is required. It is rated for use in NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosures, covering a wide range of indoor and outdoor installation environments including dust-tight and watertight locations. The screw clamp termination simplifies wiring during panel builds and service calls, and the compact body fits into tight panel layouts.

Key Features

• Rated for 480 VAC operation for direct use in higher-voltage control circuits
• Screw clamp connector for secure, tool-based field termination
• Compatible with NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosure ratings
• UL Listed (File E42259, CCN NKCR) and CSA certified (LR25490 Class 3211 03)
• CE marked for international compliance
• Compact form factor at 3.7 x 2.2 x 2.0 inches

Compatibility

Designed as an OEM-style replacement or new-installation pilot indicating light for industrial control panels and machinery requiring a 480 VAC rated pilot device with screw clamp termination.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel or circuit before installing or replacing the indicating light. Verify the supply voltage matches the 480 VAC rating of the device before restoring power. Confirm enclosure rating requirements are met for the installation environment before mounting.
