Schneider Electric 9001KP1Y31 Indicating Light 120V Yellow

Product Description

The SCHNEIDER ELECTRIC 9001KP1Y31 is a 120-volt AC indicating light with a yellow lens, designed for panel and control station applications. It uses a screw clamp connector for reliable termination without crimping tools. This pilot light is a direct-mount indicator used in industrial and commercial control panels to signal machine status, circuit state, or process conditions. Electricians and industrial maintenance technicians install these units in new panel builds and as replacement indicators in existing enclosures. The unit meets NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosure ratings, making it suitable for a range of indoor and outdoor service environments.

This indicating light is suited for use in motor control centers, machine control panels, and operator interface stations where a 120-volt AC signal source is available. The yellow lens color is commonly used to indicate a caution, standby, or intermediate process state. It fits standard pilot light mounting cutouts and is appropriate for both light industrial and heavier-duty applications given its NEMA 4 and 6 ratings.

Key Features

• 120-volt AC operating voltage for direct connection to standard control circuits
• Yellow lens for caution or process-status indication
• Screw clamp connector termination for secure, tool-free wire connection
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 rated for broad environmental compatibility
• UL Listed under File E42259, CCN NKCR
• CSA certified under LR25490 Class 3211 03 and CE marked

Compatibility

Designed as an OEM-style replacement or new-installation indicating light for 120-volt AC control panels and operator stations requiring a standard pilot light with a screw clamp connector interface.

Installation Notes

Installation is performed by a licensed electrician or qualified industrial maintenance technician. De-energize and lock out the control panel circuit before removing or installing any indicating light. Verify the panel supply voltage matches the 120-volt AC rating of this unit before making connections. Follow NEC requirements for control wiring and panel construction during installation.
