Schneider Electric 9001KP1R9 Pilot Light 120V Red Lens

Product Description

The SCHNEIDER ELECTRIC 9001KP1R9 is an incandescent pilot light designed for panel-mounted status indication in industrial and commercial control applications. It operates at 120 volts and features a round red lens that provides a clear, visible indicator of circuit status or equipment state. The screw clamp electrical connection allows for secure, tool-accessible termination without soldering. Rated for a 30mm panel cutout, this pilot light fits standard industrial enclosure knockouts and operator interface panels. Licensed electricians and panel builders install this type of device during control panel assembly or field service on existing equipment.

This pilot light is suited for use in industrial control panels, machine operator stations, and automated equipment enclosures where visual status indication is required. It is rated for NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosure types, covering a wide range of indoor and outdoor, oil-tight, and watertight installations. The 30mm form factor is a widely used standard in industrial operator interface components, making this unit a common fit in control panel layouts that follow that sizing convention.

Key Features

• 120-volt incandescent lamp for standard North American control circuit voltage
• Round red lens for immediate visual identification of circuit or equipment status
• Screw clamp connector provides reliable, serviceable field wiring termination
• 30mm panel cutout diameter matches standard industrial panel hole sizing
• Rated for NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 enclosure environments
• Meets UL 508, CSA C22.2 No. 14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C 4520, JIS C 852, and RoHS requirements

Compatibility

Designed as an OEM-style replacement or new-installation pilot light for 30mm industrial control panel operator interface cutouts requiring a 120-volt incandescent red lens indicator.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements and local codes. De-energize and lock out the control panel before installing or replacing the pilot light. Insert the unit through the 30mm panel cutout and secure using the mounting hardware, then terminate field wiring to the screw clamp connectors. Verify that the supply voltage matches the 120-volt rating before restoring power.
