Schneider Electric 9001KP1LRR31 Led Pilot Light 120V Red

Product Description

The SCHNEIDER ELECTRIC 9001KP1LRR31 is a 120 VAC LED pilot light designed for panel and control station applications. It features a round red lens and a screw clamp connector for secure, tool-assisted termination. The LED lamp type provides long service life and low current draw compared to incandescent alternatives, making it a practical choice for status indication on machine control panels, motor control centers, and industrial enclosures. Licensed electricians and industrial maintenance technicians are the primary installers of this device.

This pilot light is suited for use in residential, commercial, and industrial control panel assemblies where a 120 VAC status indicator is required. The screw clamp connector accommodates standard control wiring practices. The round lens profile fits standard 30 mm pilot light cutouts commonly found in operator interface panels and automation enclosures.

Key Features

• LED lamp type for extended service life and low power consumption
• Round red lens for clear status indication
• Screw clamp connector for secure, tool-tightened wire termination
• Rated for 120 VAC operation
• Meets multiple international and North American standards including UL 508, CSA C22.2 No. 14, and NEMA 1/2/3/3R/4/6/12/13

Compatibility

Designed as an OEM-style replacement or new-installation pilot light for 120 VAC control panels using standard 30 mm pilot light mounting formats.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before installing or replacing the pilot light. Tighten screw clamp terminals to the conductor manufacturer's recommended range using an appropriate screwdriver. Verify supply voltage matches the 120 VAC rating before energizing.
