Schneider Electric 9001KN200BP Square Blank Legend Plate

Product Description

The SCHNEIDER ELECTRIC 9001KN200BP is a square, blank plastic legend plate designed for use with 30mm pushbutton and pilot light assemblies. It features a black background with white lettering area, though the face is blank for field labeling or unmarked installations. The plate measures 1.75 inches square with a 1.2-inch hole diameter to accept standard 30mm operator hardware. Weighing approximately 0.14 pounds, it is a lightweight yet durable plastic component used in control panel assemblies across industrial and commercial electrical applications. Electricians and panel builders install this plate as a finishing and labeling component on operator devices.

This legend plate is suited for residential, commercial, and industrial control panel applications where 30mm pushbutton or pilot light stations require a clean, blank face. It is designed for use with Harmony 9001K, SK, and KX series 30mm pushbuttons and pilot lights. Common installation scenarios include machine control panels, motor control centers, and operator interface stations where a blank legend is preferred or where field-applied labels will be used.

Key Features

• Blank face legend plate with black background and white letter field for flexible field identification
• Square profile measuring 1.75 inches on each side for a clean panel finish
• 1.2-inch hole diameter sized for standard 30mm pushbutton and pilot light operators
• Lightweight plastic construction at 0.14 pounds for easy handling during panel assembly
• Compatible with Harmony 9001K, SK, and KX series 30mm operator devices
• Sold as a single unit with no minimum order quantity beyond one piece

Compatibility

Designed for use with Harmony 9001K, SK, and KX series 30mm pushbuttons and pilot lights as stated by the manufacturer.

Installation Notes

This legend plate is installed by licensed electricians or qualified panel builders during control panel assembly or maintenance. De-energize the control panel and follow lockout/tagout procedures before servicing any operator device or replacing legend plates. The plate snaps or seats into the operator bezel in accordance with the device manufacturer's assembly instructions. Consult applicable NEC guidelines for proper panel wiring and labeling requirements.
