Schneider Electric 9001KA41 Switch Contact Block No

Product Description

The SCHNEIDER ELECTRIC 9001KA41 is a replacement switch contact block designed for use with Harmony 9001K pushbutton and selector switch assemblies. It features a normally open (NO) contact configuration and a screw terminal connection, making it straightforward to wire into industrial control panels and operator interface stations. Rated at 3 amps at 240 VAC and 0.55 amps at 125 VDC, this contact block handles standard control-circuit loads. It meets multiple international and domestic standards including UL 508, CSA C22.2 No. 14, EN/IEC 60947-5-1, and RoHS requirements. Electrical contractors and industrial maintenance technicians install this type of component during new panel builds and field service calls.

This contact block is suited for light industrial and commercial control applications where Harmony 9001K series operator devices are already installed. Typical scenarios include machine control stations, motor starter panels, and operator interface enclosures. The screw terminal design accommodates standard control wiring without specialty tooling. It is commonly used when replacing worn or failed contact elements in existing Harmony 9001K assemblies rather than replacing the entire operator device.

Key Features

• Normally open (NO) contact configuration for standard control-circuit wiring
• Rated 3 amps at 240 VAC and 0.55 amps at 125 VDC
• Screw terminal connection for reliable field wiring
• Meets UL 508, CSA C22.2 No. 14, EN/IEC 60947-5-1, EN/IEC 60947-5-4, and RoHS compliance requirements
• Compact form factor: 1.9 inches long, 1.7 inches wide, 1.2 inches tall
• Lightweight at 0.1 pounds for easy handling during panel assembly

Compatibility

Designed for use with Schneider Electric Harmony 9001K series pushbutton and selector switch operator devices.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC guidelines and applicable local codes. De-energize and lock out the control panel before removing or installing contact blocks. Screw terminals should be tightened securely to prevent intermittent contact or arcing under load. Verify the contact configuration and amperage rating match the control circuit requirements before placing the assembly back in service.
