Schneider Electric 9001K2L35RH13 Push-button Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001K2L35RH13 is an illuminated, momentary push-button switch rated for 600 volts AC and 10 amps. It features a 30 mm mounting hole diameter, an extended straight red operator, and an incandescent lamp for visual status indication. The contact configuration is NC/NO, making it suitable for both normally closed and normally open control circuits. Licensed electricians and industrial controls technicians install this switch in machine control panels, motor starters, and operator interface stations where a momentary actuator with pilot-light feedback is required.

This switch is designed for use in industrial and commercial control panel applications. The extended straight operator profile suits installations where operators need positive tactile feedback or where panel depth allows for a protruding actuator. The red illuminated operator is commonly used for stop, fault, or alarm functions in control logic. It meets a broad range of standards including UL 508, CSA C22.2 No. 14, EN/IEC 60947-5-1, and JIS C 4520, making it appropriate for domestic and international panel builds.

Key Features

• 600 VAC rating supports high-voltage control circuit applications
• NC/NO contact configuration provides flexibility in control logic wiring
• Incandescent lamp illumination gives clear visual status feedback at the panel face
• Extended straight red operator for positive actuation and stop/fault circuit convention
• 30 mm mounting hole diameter fits standard 30 mm cutout enclosures and panels
• NEMA ratings 1, 2, 3, 3R, 4, 12, and 13 for broad environmental suitability

Compatibility

Designed as an OEM-style replacement or new-installation push-button switch for 30 mm industrial control panel cutouts conforming to standard operator interface mounting dimensions.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC Article 430 or the applicable local electrical code. De-energize and lock out the control panel before mounting or wiring the switch. Verify that the circuit voltage and amperage do not exceed the rated values of this device. Ensure the mounting hole is clean and correctly sized to 30 mm before seating the operator body.
