Schneider Electric 9001K2L1RH13 Push-button Switch 600V

Product Description

The SCHNEIDER ELECTRIC 9001K2L1RH13 is a heavy-duty momentary push-button switch designed for industrial and commercial control panel applications. It features a 30 mm mounting hole diameter, a red round extended (straight) push button, and screw terminal connections. Rated at 600 volts and 10 amps, it supports both NC and NO contact configurations, making it suitable for stop, start, or interlock circuits. The enclosure meets NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 ratings, providing dusttight, oiltight, and watertight protection. Licensed electricians and control panel technicians are the primary installers of this switch.

This push-button switch is used in industrial machinery, control stations, and electrical panels where a momentary operator is required. Its NEMA 4 and NEMA 6 ratings make it appropriate for wet or wash-down environments as well as standard indoor control panel installations. The NC/NO contact configuration allows flexible wiring for both normally closed safety circuits and normally open start circuits within the same unit.

Key Features

• Momentary (MO) operation with combined NC and NO contact output
• 30 mm mounting hole diameter for standard industrial panel cutouts
• Red round extended push button for quick visual identification as a stop or emergency operator
• Rated 600 volts and 10 amps for robust industrial circuit duty
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 rated — dusttight, oiltight, and watertight
• Screw terminal connections for secure, field-serviceable wiring
• Meets CE, CSA LR25490, UL (File No. E42259 CCN NKCR), and IEC Utilization Categories AC-15 and DC-13

Compatibility

Designed as an OEM-style replacement or new-installation push-button operator for 30 mm industrial control station assemblies requiring momentary NC/NO switching at up to 600 volts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before mounting or wiring this switch. Screw terminals must be torqued to the panel manufacturer or terminal manufacturer specification found in the product documentation — do not over-tighten. Verify contact configuration (NC vs. NO) against the control schematic before energizing the circuit.
