Schneider Electric 9001K1L1R Push-button Switch 600V 30mm

Product Description

The SCHNEIDER ELECTRIC 9001K1L1R is a 30 mm momentary push-button switch rated for 600 volts and designed for industrial and commercial control panel applications. It features a red, round, extended straight actuator and carries a NEMA rating of 1, 2, 3, 3R, 4, 6, 12, and 13, making it suitable for environments that demand dusttight, oiltight, and watertight protection. Certified to UL, CSA, and CE standards, this switch is built for reliable momentary contact operation in demanding electrical control circuits. Licensed electricians and panel builders install this type of component during new construction or control panel service work.

This push-button switch is used in industrial control panels, machine tool enclosures, pump control stations, and similar applications where a momentary switching action is required. Its NEMA 4 and NEMA 6 ratings make it appropriate for wash-down environments and locations exposed to splashing water, oil, or dust. The 30 mm mounting hole diameter is a standard industrial size compatible with common panel cutouts found in both light and heavy commercial installations.

Key Features

• Momentary (MO) operation for spring-return switching action
• 600-volt rating suitable for industrial control circuit voltages
• 30 mm mounting hole diameter matches standard industrial panel cutouts
• Red, round, extended straight actuator for easy visual identification
• Dusttight, oiltight, and watertight enclosure protection (NEMA 1, 2, 3, 3R, 4, 6, 12, 13)
• UL Listed, CSA certified (LR25490 Class 3211 03), and CE marked

Compatibility

Designed as an OEM-style replacement for 30 mm industrial push-button switch assemblies in control panels requiring a NEMA-rated momentary actuator.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the control panel before removing or installing any switch component. Verify that the panel cutout is 30 mm and that the enclosure rating of the assembled unit meets the environmental requirements of the installation location. Do not exceed the 600-volt rating of the switch in any control circuit application.
