Schneider Electric 9001K11J1 2-position Selector Switch 30mm

Product Description

The SCHNEIDER ELECTRIC 9001K11J1 is a 2-position maintained selector switch with a push button operator, designed for panel-mount installation in industrial and commercial control applications. The maintained (MA) operation type means the switch holds its selected position until manually moved, making it suitable for on/off or run/stop control circuits. The operator features a chrome metal bezel and mounts through a 30mm (1.18-inch) panel hole. At 0.6 pounds, this is a compact, durable switching component installed by licensed electricians and automation technicians in control panel builds and field service.

This selector switch is used in panel-mounted control stations across industrial, commercial, and heavy-duty environments. Its NEMA ratings cover a wide range of enclosure types, including NEMA 1, 2, 3, 3R, 4, 6, 12, and 13, making it appropriate for indoor general-purpose, weatherproof, watertight, and oil-tight applications. Typical installation scenarios include motor starter panels, machine control stations, and process control enclosures where a reliable, manually held switch position is required.

Key Features

• 2-position maintained (MA) operation holds switch state without continuous operator input
• Push button operator style with chrome metal bezel for durable, professional panel appearance
• 30mm panel cutout diameter fits standard 30mm control station holes
• NEMA 1, 2, 3, 3R, 4, 6, 12, and 13 rated for dust-resistant, oil-resistant, and weatherproof service
• UL Listed (File E42259, CCN NKCR) and CSA certified (LR24590 Class 3211 03) with CE marking
• Panel mount design integrates directly into standard industrial control enclosures

Compatibility

Designed as an OEM-style panel-mount selector switch for 30mm control station assemblies in NEMA-rated enclosures. Consult the manufacturer documentation to confirm compatibility with specific operator bodies, contact blocks, and legend plates in the 9001K series or equivalent 30mm mounting systems.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before removing any existing switch or installing this unit. The panel cutout must be 1.18 inches (30mm) in diameter; verify panel thickness is within the specified mounting range before securing the bezel hardware. Do not exceed the rated electrical load for the contact block used with this operator.
