Schneider Electric 700-056 Robertshaw Universal Gas Valve

Product Description

The Schneider Electric 700-056 Robertshaw Universal Gas Valve is suitable for intermittent pilot ignition applications. This valve can be adapted to work with direct spark or hot surface applications, providing versatility across various installations.

• Includes manual valve, pilot valve, and optional main gas pressure regulator.
• Compatible with central heating units, wall heaters, boilers, and mobile home furnaces.
• Features slow opening for soft ignition.

Product Highlights

Designed for both residential and commercial purposes, the Robertshaw 700-056 gas valve ensures reliable operation in diverse heating systems.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: 700-056

Technical Specifications

• Series Application: Universal Model
• Factory Part Number: 7000BDER-S7A
• Pressure Regulation: 3.5 WC Natural Gas
• Capacity: 350,000 BTU
• Inlet Size: three-fourths inch
• Outlet Size: three-fourths inch
• Electrical Rating: 24V AC at 60 Hz
• Maximum Inlet Pressure: 14 WC (1/2 PSI)
