Schneider Electric 170ADI54050 Square D 125 x 47.5 x 141.5 mm 120 VAC 125 mA 16-Channel Discrete Input Base

Product Description

This product is the Schneider Electric 170ADI54050 Square D 16-channel discrete input base designed for distributed control systems. It features a 120 VAC input voltage and provides two groups of eight inputs. The module follows IEC 1131-2 type 2 standards with isolated channels, ensuring safety. It is equipped with sixteen LEDs for channel status indication, enabling easy monitoring. The product dimensions are one hundred twenty-five millimeters wide, forty-seven point five millimeters deep, and one hundred forty-one point five millimeters high. Weighing just zero point two eighty-four kilograms, this input base is suitable for applications in infrastructure, material handling, and simple machine control. It is compliant with CE, FM Class 1 Division 2, CSA, and UL requirements. The device allows for wall mounting and is part of the Momentum range, which features modular components that snap together for flexible configurations.

• Two groups of eight inputs
• Channel status indication with 16 LEDs
• Compliant with relevant safety certifications

Product Highlights

Modular input base for control systems with extensive applications.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Catalog Number: 170ADI54050
• Input Voltage: 120 VAC
• Current Rating: 125 mA
• Dimensions: 125 mm x 47.5 mm x 141.5 mm
• Weight: 0.284 kg
• Isolation Voltage: 1780 VAC between groups
• Response Time: 10 ms (0 to 1), 35 ms (1 to 0)
• Country of Origin: France
