Schneider Electric 170ADI35000 Square D 125 x 47.5 x 141.5 mm 24 VDC 250 mA 32-Channel Discrete Input Base

Product Description

The Schneider Electric 170ADI35000 is a discrete input base module from the Modicon Momentum range. This module is designed for distributed control architecture with a discrete input voltage of twenty-four volts DC. It contains two groups of sixteen inputs, conforming to IEC 1131-2 type one with positive discrete input logic. The isolation between channels and ground is five hundred volts AC. The module features thirty-two LEDs for signaling channel status. It has dimensions of one hundred twenty-five millimeters by forty-seven point five millimeters by one hundred forty-one point five millimeters and a weight of zero point two kilograms. Major applications of this module include infrastructure and energy management, material handling, and simple machine control. The product meets certification standards, including CE, CSA, and UL, and is suitable for wall mounting.

• Discrete input base for distributed control
• Features thirty-two channel status LEDs
• Certified by CE, CSA, and UL

Product Highlights

Part of the flexible Modicon Momentum system, allowing for versatile control applications and easy snap-together installation.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• MPN: 170ADI35000
• Depth: 47.5 mm
• Width: 125 mm
• Height: 141.5 mm
• Weight: 0.2 kg
• Current: 250 mA
• Power Supply: 24 VDC
• Response Time: 2.2 ms (state 0 to state 1), 3.3 ms (state 1 to state 0)
