Schlage ND170-RHO-626 ND170 RHO 626

Product Description

The Schlage ND170-RHO-626 is a cylindrical single dummy trim lock featuring the Rhodes lever. This Grade 1 lock is designed for commercial use and does not require any key. It meets ANSI/BHMA A156.2 standards for high security and durability. The lock is suitable for both new constructions and retrofit projects.

• Single dummy function for one side of the door.
• Exceeds ANSI/BHMA Grade 1 operational and security standards.
• UL listed for 3-hour fire door.

Product Highlights

This product is a reliable choice for securing doors in commercial settings.

Product Information

Standard Information

• Brand: Schlage
• MPN: ND170-RHO-626

Technical Specifications

• Chassis: Zinc and steel components with zinc dichromate plating for corrosion resistance
• Door thickness: 1-5/8 inches to 2-1/8 inches (41 mm to 54 mm) standard; optional for 1-3/8 inches to 6 inches (35 mm to 152 mm)
• Handing: Non-handed
• Trim Options: Nine lever designs made of pressure cast zinc
• Roses: Wrought brass, plated to match the finish
• Latches Backset: Standard is 2-3/4 inches (70 mm); options include 2-3/8 inches, 3-3/4 inches, and 5 inches
• Latchbolt: 1/2 inch (13 mm) throw, oil impregnated stainless steel
• Faceplate: Square corner sizes available
