Schlage Lock B563-J-626 B563J626 B563J 626 Less Full Sz Removeable Core

Product Description

The SCHLAGE LOCK B563-J-626 is a B563J626 B563J 626 less full size removable core. This deadbolt is designed for commercial applications. It meets or exceeds ANSI/BHMA Grade 2 standards for security and operation. The deadbolt features a solid zinc bolt with a hardened steel anti-saw pin. It is easy to install and can meet any security need.

• Meets or exceeds ANSI/BHMA Grade 2 operational and security standards
• Solid zinc bolt with hardened steel anti-saw pin
• Upgradeable to UL 10C 3-hour fire rated options (as auxiliary locks) except B562 & B571

Product Highlights

This Schlage B500 Series Grade 2 deadbolt offers strength, durability, and versatility. It features anti-saw, anti-pry, and anti-wrench security features.

Product Information

Standard Information

• Brand: SCHLAGE LOCK
• Manufacturer Part Number: B563-J-626
• Country of Origin: United States

Technical Specifications

• Brand: Schlage
• MPN: B563J626
• UPC: Does not apply
• Category: Mechanical Commercial Locksets
• SubCategory: Commercial Deadbolts
• Series: B500 Series
• Backset: Adjustable 2-3/8" or 2-3/4" Backset
• Strike: Square Corner Deadbolt Strike
• Crossbore Size: 1-1/2" or 2-1/8" Bore
• Finish Description: Satin Chrome
• Material: Zinc Base
• Function: Classroom Deadbolt
• Deadbolt: 1" housing diameter; 0.81" x 0.62" x 1" throw
• Faceplate: square corner 1-1⁄8" x 2-1/4" (29 mm x 57 mm) standard; circular drive-in style in and round corner options available
• ANSI/BHMA: ANSI/BHMA A156.36-2020, Grade 2 auxiliary lock (except B581) With SFIC interchangeable core cylinders: Grade 3
• ADA: ADA compliant thumbturn designs
• UL/cUL: Available UL 10C and CAN/ULC-S104 listed (except B562) 3-hour fire rated as auxiliary locks Letter F and UL symbol on latch front indicate listing UL 10B listed for neutral pressure doors UL 437 listed when using Primus high-security UL 437 cylinder
• California Fire Code: Meets Building Code requirements
• BAA/TAA: Meets
• ANSI Certified: A156.36
• Door Range: 1-3/8" to 1-7/8"
• UL Listed: for 3 Hour Fire Door
• Door Thickness: Standard door thickness: 1-3/8" to 2-1/4" (35 mm to 57 mm) conventional cylinder or door bolt; 1-3/8" to 2" (35 mm to 51 mm) FSIC or SFIC
• Manufacturer_Warranty: Limited 3 Year Mechanical Warranty
