Schlage F80BEL626 Satin Chrome Storeroom Bell Knobset

Product Description

The SCHLAGE F80BEL626 is a satin chrome storeroom bell knobset designed for commercial and light commercial door applications where controlled access is required. The outside knob is fixed at all times and can only be unlocked by key, while the inside knob remains always unlocked, making it suited for storeroom and supply room doors. The unit features a 5-pin cylinder with two nickel silver cut keys included per lock. Interior mounting screws are exposed. The adjustable backset accommodates door thicknesses from 1-3/8 inches to 1-7/8 inches, giving installers flexibility across a range of door types.

This knobset is intended for storeroom function doors in commercial, institutional, or light commercial settings. It installs into a standard 2-1/8 inch bore face hole with a 7/8 inch latch hole. The F80BEL626 ships with multiple faceplate and strike plate options, allowing it to fit square corner and round corner door preps without additional hardware. It is appropriate for new construction and retrofit installations where a storeroom lockset in a satin chrome finish is specified.

Key Features

• Storeroom function: outside knob always locked, inside knob always unlocked
• 5-pin cylinder with two nickel silver cut keys included
• Adjustable door thickness from 1-3/8 inches to 1-7/8 inches
• Standard 2-1/8 inch face bore with 7/8 inch latch hole prep
• Includes 1/4 inch round corner, square corner, and drive-in faceplates (Part 16-211)
• Includes square corner and round corner full lip strike plates (Part 10-063), 2-1/4 inches x 1-5/8 inches

Compatibility

Designed as a replacement or new-installation storeroom knobset for standard commercial and residential doors with a 2-1/8 inch cross bore and 7/8 inch latch hole. Compatible faceplate part number is 16-211 and strike plate part number is 10-063 as supplied.

Installation Notes

Installation should be performed by a licensed locksmith or qualified door hardware installer in accordance with applicable building codes. Power is not required for this mechanical lockset. Verify door thickness is within the 1-3/8 inch to 1-7/8 inch adjustable range before installation. Select the appropriate faceplate corner style to match the existing door mortise prior to setting the latch.
