Schlage Commercial B560R613 Grade 2 Deadbolt Oil Rubbed Bronze

Product Description

The SCHLAGE COMMERCIAL B560R613 is a Grade 2 single cylinder deadbolt featuring a full size interchangeable core (FSIC) with a C keyway, shipped 1-bitted for field keying. It ships with the 12287 latch and 10094 strike plate included. Designed for commercial and institutional door applications, this deadbolt delivers reliable mechanical security in an oil rubbed bronze finish. Licensed locksmiths, commercial door hardware installers, and facilities maintenance technicians are the primary trades that specify and install this hardware on hollow metal and solid wood door assemblies.

The B560R613 is suited for commercial buildings, multi-family residential properties, and institutional facilities where interchangeable core keying systems are already in place or being installed. The full size interchangeable core design allows cores to be swapped without removing the lock body from the door, which supports master key system management and rekeying efficiency on large keyway programs using the C keyway family. The oil rubbed bronze finish coordinates with standard commercial door hardware trim packages.

Key Features

• Grade 2 single cylinder deadbolt construction for commercial-grade security
• Full size interchangeable core (FSIC) design allows core removal and replacement without disassembling the lock body
• C keyway with 1-bitted core included, ready for field keying into an existing master key system
• Includes 12287 latch and 10094 strike for complete installation out of the box
• Oil rubbed bronze (613) finish for compatibility with standard commercial trim packages
• Sold individually; case quantity of 4 units available

Compatibility

Designed for use in commercial and institutional door applications with full size interchangeable core keying systems using the C keyway. Specific door or frame compatibility should be verified against the door prep and backset requirements prior to installation.

Installation Notes

Installation should be performed by a licensed locksmith or qualified commercial door hardware technician familiar with ANSI Grade 2 deadbolt installation standards. Verify the door thickness, backset, and bore dimensions match the lock specifications before beginning. Ensure the door is closed and the latch and strike are properly aligned before final screw torque to avoid binding. Core insertion and removal requires the appropriate control key for the FSIC system in use.
