Schlage Commercial B560P622 Grade 2 Single Cylinder Deadbolt

Product Description

The SCHLAGE COMMERCIAL B560P622 is a Grade 2 single cylinder deadbolt designed for light commercial and residential applications where reliable door security is required. It features a C keyway configuration, ships keyed different (KD) with a KA4 keying option, and includes a 12287 latch and 10094 strike plate. The matte black finish (622) provides a clean, low-sheen appearance suited to modern door hardware installations. This deadbolt is installed by locksmiths, commercial door hardware contractors, and facilities maintenance technicians.

The B560P622 is appropriate for interior and exterior doors in light commercial buildings, multi-family residential properties, and institutional settings. The single cylinder configuration accepts a key from the exterior while the interior is operated by a thumbturn. The included latch and strike hardware allow for a complete installation without sourcing separate components. The C keyway is a standard commercial keyway that integrates readily into existing Schlage C keyway master key systems.

Key Features

• Grade 2 single cylinder deadbolt suitable for light commercial and multi-family residential use
• C keyway configuration compatible with standard Schlage C keyway cylinders
• Ships keyed different (KD) with KA4 keying option for master key system integration
• Includes 12287 latch and 10094 strike plate for a complete installation package
• Matte black 622 finish for a consistent appearance with coordinating door hardware
• Compact profile at 5.7 inches long, 4.4 inches wide, and 3.1 inches high

Compatibility

Designed as an OEM-style Grade 2 deadbolt replacement or new installation for standard single-bore residential and light commercial doors using the Schlage C keyway system.

Installation Notes

Installation is performed by a licensed locksmith or qualified door hardware technician following standard ANSI deadbolt prep guidelines. Ensure the door is properly prepared with a standard 2-1/8 inch bore and 1 inch cross-bore before fitting the unit. Verify strike plate alignment and door frame reinforcement to ensure proper bolt throw engagement. Always confirm the door is secured open and power to any adjacent electronic hardware is isolated before beginning work.
