Schaeffler 6315-2Z-C3 Single Row Deep Groove Radial Ball Bearing 75 mm Bore x 160 mm OD x 37 mm W

Product Description

The Schaeffler 6315-2Z-C3 is a single row deep groove radial ball bearing with a bore diameter of seventy-five millimeters and an outside diameter of one hundred sixty millimeters. This bearing features a width of thirty-seven millimeters and comes with double shields made from sheet steel for enhanced protection against contaminants.

• Versatile design suitable for various applications
• High load capacity with low friction for efficient performance
• Dynamic load capacity of one hundred twenty-three thousand Newtons

Product Highlights

This bearing is designed for high-speed applications and can support both radial and axial loads efficiently.

Product Information

Standard Information

• Brand: Schaeffler Group
• MPN: 6315-2Z-C3

Technical Specifications

• Bore Diameter: 75 mm
• Outside Diameter: 160 mm
• Width: 37 mm
• Cage Material: Sheet Steel
• Dynamic Load Capacity: 123000 N
• Static Load Capacity: 77000 N
• Clearance: C3
• Temperature Rating: -30 to 120 degrees Celsius
