Product Description
The SATCO S11827R1 is a 12W integrated LED direct wire downlight with an edge-lit design and remote driver. This 6-inch downlight features selectable CCT from 2700K to 5000K and delivers 1050 lumens with a 110-degree beam angle. It is suitable for indoor and outdoor use and is dimmable.
- Features edge-lit design and a remote driver.
- Offers selectable CCT options from 2700K to 5000K.
- Suitable for indoor and outdoor use and is sloped ceiling compatible.
Product Highlights
This 12W LED downlight provides 1050 lumens, is dimmable, and has a 50,000-hour rated life. It is Energy Star certified, FCC compliant, RoHS compliant, and cETLus listed.
Product Information
Standard Information
-
Brand: SATCO
-
Manufacturer Part Number: S11827R1
-
Country of Origin: China
Technical Specifications
-
Company: SATCO
-
Mounting Height: 1.34
-
Mounting Length: 6.18
-
Bulb Included: Integrated
-
Center Beam Candle Power: 400
-
Diameter: 6.75
-
Dimmable Text: Line Voltage; 120V Only
-
Material: Aluminum
-
Fixture Type: Non Removable
-
Style: Utility
-
Surge Protection: Built-in surge protection - 2.5KV
-
Total Harmonic Distortion: <20%
-
Up Down Installation: Down
-
CCT Selectable: Yes
-
Wattage Selectable: No
-
Finish Family: White
-
Amps: 0.120A
-
Has Camera: No
-
IOT Enabled: No
-
Lens Finish: Frost
-
Lens Material: Poly methyl methacrylate (PMMA)
-
Nominal Length: 6.0
-
Power Factor: >0.9
-
SDS Class: LED_Fixture
-
Sloped Ceiling Compatible: Yes
-
Indoor Outdoor: Indoor and Outdoor
-
Product Technology: LED
-
Incandescent Equivalent: 75W
-
CCT (Kelvin Temp): 2700K/3000K/3500K/4000K/5000K
-
Dimmable: Yes-Dimmable
-
Hours Rated: 50000
-
Beam Angle (degree): 110
-
Color Temp: Warm White to Natural Light
-
CRI: 90+
-
Dimming Type: Linear Dimming, Phase cut
-
Operating Frequency: 60Hz
-
Operating Temp: -20C (-4F) to +45C (+113F)
-
Lumens: 1050L
-
Volts: 120v
-
Watts: 12W
-
Lamp Base: Integrated
-
Finish: WHITE
-
ANSI Base: Integrated
-
Lamp Type: Integrated LED
-
Fixture Shape: Round
-
Room Type: Bedroom
-
Specific Uses For Product: Indoor use only
-
Indoor Outdoor Usage: Indoor
-
Power Source: AC
-
Light Source: LED
-
Voltage: 120 Volts
-
Lighting Method: Downlight
-
Brightness: 1050 Lumen
-
Required Assembly: No
-
Avg. Life (Hours): 50000
-
Kelvin Temp.: 2700-5000 Selectable
-
Max Operating Temp: 113 F (45 C)
-
Min Operating Temp: -4 F (-20 C)
-
Certifications: cETLus | RoHS Compliant | FCC
-
UPC Code: #045923411052
-
Outdoor Rating: Wet Location Rated
-
Height: 0.99 in
-
Width: 6.75 in
-
Brand: Satco
-
Type: Satco Integrated LED Ceiling Light Fixture Retrofit Kit
-
MPN: S11827R1
-
Country of Origin: China
-
Nominal Size (in.): 6 in
-
UPC: 045923411052
