Product Description
The SATCO 65-813 is an LED UFO High Bay fixture designed for industrial and commercial environments. This fixture offers selectable wattage options of 150W, 175W, or 200W, and CCT selectable options of 3000K, 4000K, or 5000K. Operating on 120-347 Volt, it features a durable die-cast aluminum construction and an integrated sensor port. With a 90-degree beam angle and 0-10V dimming, it provides versatile illumination. It is rated for wet locations with an IP65 rating and includes built-in 6KV surge protection.
- Wattage selectable (150W/175W/200W) and CCT selectable (3000K/4000K/5000K) for flexible lighting.
- Durable die-cast aluminum construction with IP65 wet location rating and built-in 6KV surge protection.
- Features 0-10V dimming, an integrated sensor port, and a 90-degree beam angle.
Product Highlights
Versatile LED UFO high bay with selectable wattage and CCT, 0-10V dimming, and robust IP65 wet location rating.
Product Information
Standard Information
-
Brand: SATCO
-
Manufacturer Part Number: 65-813
-
Country of Origin: Vietnam
Technical Specifications
-
Bulb Included: Integrated
-
Diameter: 13.4 inches
-
Material: Die-cast Aluminum
-
Fixture Type: UFO Hi-Bay
-
Includes: Locking Hanging Hook; 6 Foot Whip
-
Surge Protection: 6KV
-
Total Harmonic Distortion: 15%
-
Wire Length: 72.0 inches
-
CCT Selectable: Yes
-
Wattage Selectable: Yes
-
Finish: White
-
Amperage: 1.250-0.432A / 1.458-0.504A / 1.667-0.576A
-
Integrated Features: Integrated Sensor Port
-
Lens Finish: Clear
-
Lens Material: Polycarbonate (PC)
-
Photocell: Optional Add-On
-
Power Factor: 0.9
-
Location Type: Indoor
-
Technology: LED
-
Incandescent Equivalent: 1000W/1500W/2000W
-
Color Temperature (CCT): 3000K/4000K/5000K
-
Dimmable: Yes
-
Rated Life: 50000 hours
-
Beam Angle: 90 degrees
-
Light Color: Warm White to Natural Light
-
CRI: 80+
-
Dimming Type: 0-10V Dimming
-
Operating Frequency: 50/60Hz
-
Operating Temperature: -40F to +122F (-40C to +50C)
-
HID Equivalent: 400W-450W
-
Lumens: 22200-28800L
-
Input Voltage: 120V-347V
-
Wattage: 150W/175W/200W
-
Lamp Base: Integrated
-
Fixture Shape: Round
-
Mounting Height: Up to 20 feet
-
DLC ID: S-PQ3SZK
-
FCC Compliant: Yes
-
IP Rating: IP65
-
Location Rating: Wet
-
NSF Approved: Yes
-
RoHS Compliant: Yes
-
Safety Listing: cULus - Certified
-
DLC Approved: Yes
-
California Title 20: Exempt
-
T24/JA8 Compliant: No
-
Height: 7.3 inches
-
Mounting Type: Pendant
-
DLC Classification: Premium
