Product Description
The SATCO 65-771R3 LED UFO Highbay is a versatile lighting fixture with selectable wattage (150W/175W/200W) and CCT (3000K/4000K/5000K). Operating on 120-347 Volts, this high bay light is constructed from die-cast aluminum and features a black finish. It is designed for various industrial and commercial applications, including warehouses and manufacturing facilities, providing efficient and adjustable illumination. The fixture includes built-in 6KV surge protection and is 0-10V dimmable.
- Wattage selectable (150W/175W/200W) and CCT selectable (3000K/4000K/5000K)
- Operates on 120-347 Volts with 0-10V dimming capability
- Durable die-cast aluminum construction with IP65 wet location rating and 6KV surge protection
Product Highlights
Versatile LED UFO high bay with adjustable wattage and color temperature for industrial and commercial use.
Product Information
Standard Information
-
Brand: SATCO
-
Manufacturer Part Number: 65-771R3
Technical Specifications
-
MPN: 65-771R3
-
Alternative MPN: 65/771R3
-
Bulb Included: Integrated
-
Diameter: 13.4 inches
-
Material: Die-cast Aluminum
-
Fixture Type: UFO High Bay
-
Included Accessories: Locking Hanging Hook, 6 Foot Whip
-
Style: Utility
-
Surge Protection: 6KV
-
Total Harmonic Distortion: 15%
-
Wire Length: 72.0 inches
-
CCT Selectable: Yes
-
Wattage Selectable: Yes
-
Finish: Black
-
Amperage: 1.250-0.432A / 1.458-0.504A / 1.667-0.576A
-
Integrated Features: Sensor Port
-
Lens Finish: Clear
-
Lens Material: Polycarbonate (PC)
-
Lensed: Yes
-
Photo Cell: Optional Add-On
-
Power Factor: 0.9
-
Location Use: Indoor
-
Technology: LED
-
Incandescent Equivalent: 1000W/1500W/2000W
-
Color Temperature (CCT): 3000K/4000K/5000K
-
Dimmable: Yes
-
Rated Life: 50000 Hours
-
Beam Angle: 90 degrees
-
CRI: 80+
-
Dimming Type: 0-10V
-
Operating Frequency: 50/60Hz
-
Operating Temperature: -40F to +122F (-40C to +50C)
-
HID Equivalent: 400W-450W
-
Lumens: 22200-28800
-
Input Voltage: 120-347V
-
Wattage: 150W/175W/200W
-
Lamp Base: Integrated
-
Lamp Type: Integrated LED
-
Fixture Shape: Round
-
Mounting Height: Up to 20 feet
-
IP Rating: IP65
-
Location Rating: Wet
-
FCC Compliant: Yes
-
NSF Approved: Yes
-
RoHS Compliant: Yes
-
Safety Listing: cULus Certified
-
DLC Approved: Yes
-
Height: 7.3 inches
