Satco 65/700R1 2 foot LED linear strip light 15W/20W/25W 65-700

Product Description

The SATCO 65/700R1 is a 2-foot LED Linear Strip Light designed for versatile indoor lighting applications. This fixture offers field-selectable CCT (3500K, 4000K, 5000K) and wattage (15W, 20W, 25W), providing adjustable illumination from 1950 to 3500 lumens. Operating on 120V-277V, it features 0-10V dimming and built-in 2KV surge protection. Constructed from steel with a polycarbonate lens, it is suitable for damp locations and sloped ceilings.

• Field selectable wattage (15W/20W/25W) and CCT (3500K/4000K/5000K) for customizable lighting
• Dimmable with 0-10V dimming and features built-in 2KV surge protection for enhanced durability
• Rated for 50,000 hours, suitable for indoor damp locations and compatible with sloped ceilings

Product Highlights

Versatile LED linear strip light with adjustable CCT and wattage, 0-10V dimming, and 2KV surge protection.

Product Information

Standard Information

• Brand: SATCO
• Manufacturer Part Number: 65/700R1
• Country of Origin: China

Technical Specifications

• Company: NUVO
• Bulb Included: Integrated
• Material: Steel
• Fixture Type: Strip Light
• Style: Utility
• Surge Protection: Built-in surge protection - 2KV
• Total Harmonic Distortion: 13.61%
• CCT Selectable: Yes
• Wattage Selectable: Yes
• Amps: 0.125-0.054/0.167-0.072/0.208-0.090A
• Lens Finish: White
• Lens Material: Polycarbonate (PC)
• Photocell: Optional Add-On
• Power Factor: 0.9
• Sloped Ceiling Compatible: Yes
• Indoor Outdoor: Indoor
• Technology: LED
• Incandescent Equivalent: 150W-175W
• Color Temperature: 3500K/4000K/5000K
• Dimmable: Yes-Dimmable
• Rated Hours: 50000
• Beam Angle: 120°
• Light Color: Neutral White to Daylight
• CRI: 80+
• Dimming Type: 0-10V Dimming
• Operating Frequency: 50/60Hz
• Operating Temperature: -4F to +140F (-20C to +60C)
• Lumens: 1950L-3500L
• Input Voltage: 120V-277V
• Power Consumption: 15W/20W/25W
• Lamp Base: Integrated
• Finish: White
• BUG Rating: B1-U3-G1
• IP Rating: IP20
• Location Rating: Damp
• Mounting Type: Ceiling/Wall
• Connection: Hardwire
• Has Driver: Yes
