Product Description
The SATCO 65-632R1 is an LED canopy fixture designed for outdoor applications, featuring an integrated sensor port and CCT selectable functionality. This 100W fixture provides 14298L/15322L/14943L lumens with a 150-degree beam angle, offering 3000K, 4000K, or 5000K color temperatures. Constructed from die-cast aluminum with a bronze finish, it is IP65 rated for wet locations and includes built-in 6KV surge protection, ensuring durability and performance in various environments. It is also 0-10V dimmable.
- 100 Watt LED Canopy Fixture with CCT Selectable (3000K/4000K/5000K) functionality.
- Integrated Sensor Port and built-in 6KV surge protection for enhanced utility and durability.
- IP65 rated for wet locations, constructed from die-cast aluminum with a bronze finish, and 0-10V dimmable.
Product Highlights
Durable 100W LED canopy fixture with CCT selection, integrated sensor port, 6KV surge protection, and wet location rating.
Product Information
Standard Information
-
Brand: SATCO
-
Manufacturer Part Number: 65-632R1
-
Country of Origin: Vietnam
Technical Specifications
-
Manufacturer: NUVO
-
Bulb Included: Integrated
-
Diameter: 11.02 in
-
Material: Die-cast Aluminum
-
Fixture Type: Canopy
-
Finish Coating: UV Stabilized Powder Coated
-
Style: Utility
-
Surge Protection: 6KV
-
Total Harmonic Distortion: <20%
-
CCT Selectable: Yes
-
Wattage Selectable: No
-
Finish Family: Bronze
-
Current: 0.833-0.361A
-
Integrated Features: Sensor Port
-
Lens Material: Polycarbonate (PC)
-
Photocell: Optional Add-On
-
Power Factor: >0.9
-
Location: Outdoor
-
Technology: LED
-
Incandescent Equivalent: 500W
-
Color Temperature: 3000K/4000K/5000K
-
Dimmable: Yes
-
Rated Life Hours: 50000
-
Beam Angle: 150 Degree
-
Color of Light: Warm to Cool White
-
CRI: 80+
-
Dimming Type: 0-10V
-
Operating Frequency: 50/60Hz
-
Operating Temperature: -40F to +113F (-40C to +45C)
-
Lumens: 14298L/15322L/14943L
-
Input Voltage: 120V-277V
-
Wattage: 100W
-
Base Type: Integrated
-
Finish: Bronze
-
ANSI Base: Integrated
-
Lamp Type: Integrated LED
-
Fixture Shape: Round
-
BUG Rating: B3-U3-G2
-
IP Rating: IP65
-
Location Rating: Wet
-
Height: 3.15 in
-
Width: 11.02 in
-
Depth: 11.02 in
-
Driver Included: Yes
-
Mounting Type: Ceiling
-
Voltage Type: AC Only
-
Fixture Application: Area/General Lighting
-
Shade/Lens Color: White
