Product Description
The SATCO 65-556 is an LED Full Cutoff Wall Pack, featuring field-selectable wattage (80W/100W/120W) and color temperatures (3000K/4000K/5000K). Operating on 120-347 Volts, this fixture is designed for outdoor illumination and security. It includes an integrated photocell, 0-10V dimming, and built-in 6KV surge protection. Constructed from die-cast aluminum, it is IP65 rated for wet locations, providing 12107-17789 lumens with a 50,000-hour rated life.
- Field-selectable wattage (80W/100W/120W) and color temperature (3000K/4000K/5000K) for versatile lighting.
- Integrated photocell with bypass option and 0-10V dimming for enhanced control.
- IP65 rated die-cast aluminum construction with 6KV surge protection for outdoor durability.
Product Highlights
This LED wall pack offers adaptable illumination with field-selectable CCT and wattage, robust IP65 outdoor durability, and integrated controls for efficient security and perimeter lighting.
Product Information
Standard Information
-
Brand: SATCO
-
Manufacturer Part Number: 65-556
-
Country of Origin: Vietnam
Technical Specifications
-
Bulb Type: Integrated LED
-
Extension: 8.11 inches
-
Material: Die-cast Aluminum
-
Fixture Type: Wall Pack
-
Light Distribution: Type II
-
Style: Utility
-
Surge Protection: 6KV
-
Total Harmonic Distortion: <20%
-
CCT Selectable: Yes
-
Wattage Selectable: Yes
-
Finish: Bronze
-
Amperage: 0.667-0.231A (80W), 0.833-0.288A (100W), 1.000-0.346A (120W)
-
Integrated Features: Photocell, Sensor Port
-
Lens Finish: Opaque
-
Lens Material: Polycarbonate (PC)
-
Photocell: Yes (Bypassable)
-
Power Factor: >0.9
-
Location: Outdoor
-
Technology: LED
-
Color Temperature: 3000K/4000K/5000K (Field Selectable)
-
Dimmable: Yes
-
Rated Life: 50000 hours
-
Beam Angle: 106 degrees
-
Color Range: Soft White to Natural Light
-
CRI: 80+
-
Dimming Type: 0-10V
-
Operating Frequency: 50/60Hz
-
Operating Temperature: -40°F to +122°F (-40°C to +50°C)
-
HID Equivalent: 400W
-
Lumens: 12107-17789
-
Input Voltage: 120-347V
-
Wattage: 80W/100W/120W
-
Lamp Base: Integrated
-
Lamp Type: Integrated LED
-
BUG Rating: B2-U0-G2
-
IP Rating: IP65
-
Location Rating: Wet
-
RoHS Compliant: Yes
-
Safety Listing: cULus
-
Product Type: LED Full Cutoff Wall Pack
-
Connection Type: Hardwire
-
Mounting Type: Wall
-
Sensor Operating Temperature: -25°C (-13°F) to +50°C (+122°F)
-
Sensor Type: PIR
-
Voltage Type: Range Voltage/AC Only
