Satco 65-1512 led selectable linear high bay 240w/220w/180w 45x100/65x95/90x90 replaces 65-1012

Product Description

The SATCO 65-1512 LED Linear High Bay is a versatile lighting solution featuring selectable wattage (240W, 220W, 180W), CCT (3000K, 4000K, 5000K), and beam angles (45x100, 65x95, 90x90 degrees). Operating on 120V-347V, this fixture provides 28000-38000 lumens and is rated for 50,000 hours. Constructed from die-cast aluminum with a clear polycarbonate lens, it includes built-in 6KV surge protection and 0-10V dimming capability. Ideal for indoor damp locations, it ensures efficient and adaptable illumination for various commercial and industrial settings.

• Wattage selectable (240W/220W/180W)
• CCT selectable (3000K/4000K/5000K)
• Beam angle selectable (45x100/65x95/90x90 degrees)

Product Highlights

This LED linear high bay offers adjustable wattage, color temperature, and beam angles for flexible lighting designs in commercial and industrial environments.

Product Information

Standard Information

• Brand: SATCO
• Manufacturer Part Number: 65-1512
• Country of Origin: Vietnam

Technical Specifications

• Lamp Type: Integrated LED
• Chain Length: 41 in
• Body Material: Die-cast Aluminum
• Product Type: Linear High Bay
• Surge Protection: 6KV
• THD: <20%
• CCT Selectable: Yes
• Wattage Selectable: Yes
• Finish: White
• Amperage: 2.000-0.690/1.830-0.630/1.500-0.520A
• Integrated Features: Integrated Sensor Port
• Lens Finish: Clear
• Lens Material: Polycarbonate
• Operating Humidity: 20% to 90% R.H.
• Power Factor: >0.9
• Location: Indoor
• Technology: LED
• Fluorescent Equivalent: 400W-570W
• CCT: 3000K/4000K/5000K
• Dimmable: Yes
• Rated Life: 50000 hours
• Beam Angle: 45x100/65x95/90x90 degrees
• CRI: 80+
• Dimming Type: 0-10V
• Operating Frequency: 50/60Hz
• Operating Temperature: -40F to +122F (-40C to +50C)
• HID Equivalent: 350W-450W
• Lumens: 28000-38000 lm
• Input Voltage: 120V-347V
• Wattage: 240W/220W/180W
• Lamp Base: Integrated
• ANSI Base: Integrated
• Fixture Shape: Linear
• CA Prop 65: Lead
• DLC ID: S-BQTMNS
• FCC Compliant: Yes
• IP Rating: IP20
• Location Rating: Damp
• NSF Approved: No
• RoHS Compliant: Yes
• Safety Listing: cULus Listed
• DLC Approved: Yes
• Title 20: Exempt
• T24/JA8 Compliant: No
• DLC Classification: Premium
• DLC Primary Use: High-Bay Luminaires for Commercial and Industrial Buildings
• Has Driver: Yes
• Has Emergency Battery: No
• Mounting Type: Ceiling
• Replaceable Light Source: No
• Sensor Type: Daylight
