Sandvik Coromant 5763114 Cap Screw Torx Plus M6

Product Description

The SANDVIK COROMANT 5763114 is a Torx Plus cap screw designed to secure indexable inserts in toolholders used on CNC lathes, milling machines, and other cutting tool platforms. With an M6 thread size and a compact profile measuring 0.91 inches in length and 0.35 inches in width and height, this screw provides reliable clamping force to keep inserts properly seated during machining operations. It weighs approximately 0.25 pounds per package and meets industry standard 5512 084-02. Tooling technicians and machinists install this fastener as a direct service component when replacing worn or damaged clamping hardware on indexable toolholders.

This cap screw is suited for use in toolholder maintenance across production machining environments, including both manual and CNC applications. It is compatible with toolholders requiring an M6 Torx Plus drive screw and serves as a replacement component to maintain insert security and cutting performance. Sold individually with a minimum order quantity of 10 units, it is a standard consumable for shops that regularly service indexable tooling assemblies.

Key Features

• M6 thread size for use with compatible indexable toolholders
• Torx Plus drive type for positive engagement and reduced cam-out during installation
• Meets industry standard 5512 084-02
• Compact dimensions: 0.91 inches length, 0.35 inches width, 0.35 inches height
• Sold individually; minimum order quantity of 10 units

Compatibility

Compatible with indexable toolholders requiring an M6 Torx Plus cap screw per industry standard 5512 084-02.

Installation Notes

Installation is typically performed by a machinist or tooling technician during insert changes or toolholder servicing. Ensure the machine spindle is fully stopped and the toolholder is secured before removing or installing the screw. Use the correct Torx Plus key to avoid stripping the drive recess. Do not overtighten — follow the toolholder manufacturer's torque guidance for M6 clamping screws.
