Sandvik Coromant 5763101 Cap Screw Torx Plus M4

Product Description

The SANDVIK COROMANT 5763101 is a Torx Plus drive cap screw designed for securing indexable inserts in cutting tool assemblies. This screw uses an M4 thread and is built specifically as an assembly screw for indexable tooling systems. It measures 0.47 inches in length, 0.39 inches in height, and 0.39 inches in width, and weighs 0.25 pounds per package. Machining professionals and toolroom technicians install this fastener when replacing or repositioning carbide inserts on turning, milling, or boring tool bodies that require a Torx Plus drive for precise torque application and reduced cam-out risk.

This cap screw is used in machine shop and production environments where indexable insert tooling is standard. It suits applications in CNC turning centers, milling machines, and boring bars where M4 Torx Plus insert screws are specified. The minimum order quantity is 5 units, making it appropriate for tool crib restocking and preventive maintenance kits. It corresponds to industry standard number 5512 090-08, which aids cross-referencing with tooling catalogs and maintenance documentation.

Key Features

• Torx Plus drive reduces cam-out during insert seating and removal
• M4 thread size matches standard indexable tooling screw specifications
• Compact dimensions: 0.47 inches length, 0.39 inches height, 0.39 inches width
• Industry standard number 5512 090-08 for catalog cross-reference
• Sold in multiples of 5 to support tool crib and maintenance inventory

Compatibility

Designed as an OEM-style assembly screw for SANDVIK COROMANT indexable tooling systems requiring an M4 Torx Plus cap screw. Verify thread size and drive type against the specific tool body before ordering.

Installation Notes

This fastener is installed by machinists and toolroom technicians during indexable insert changes or tooling assembly. Power down and lock out the machine before accessing any cutting tool components. Use a calibrated Torx Plus driver or torx key of the correct size to seat the screw properly. Refer to the tool body manufacturer torque specification chart for the correct seating torque, as over-tightening can damage the screw or insert pocket.
