The SAMSUNG NZ30FG6332RKAA 30" Electric Cooktop uses powerful heat for fast and even cooking. The 5-element flexible cooktop includes a rapid boil burner with 2 rings for different sized pots and pans. It features blue LED illuminated knobs and a hot surface indicator light. The smooth glass, ceramic electric cooktop makes cleaning effortless.
Rapid Boil burner provides a powerful, controlled heat source.
The 5-element flexible cooktop includes a warming center.
Blue LED lights illuminate when the cooktop is in use.
Product Highlights
This cooktop offers Wi-Fi connectivity, easy-to-clean glass surface, and front controls for easy access.
Product Information
Standard Information
Brand: SAMSUNG
Manufacturer Part Number: NZ30FG6332RKAA
Technical Specifications
Width
30 Inches
Height
5.125 Inches
Depth
21.25 Inches
Installation Type
Built-in
Cooktop Frame
Frameless
Control Type
Mechanical Knob
Total Power (kW)
8.1 kW
Element - Left Front
7”, 1500 W
Element - Left Rear
Warming center , 100 W
Element - Right Front
5”/8”, 2000 W
Element - Right Rear
6”, 1200 W
Element - Center
6”/9”, 3300 W
Power Level
3
Power Supply
240V/60Hz (8.1 kW), 208V/60Hz (6.1kW)
ENERGY STAR® Certification
Yes
Child Safety Lock
No
Surface
Black Glass
Simmer/Melt
Yes
Kitchen Timer
No
Power On/Off
Yes
Number of Burner
5 EA
Hot Surface Indicator
Yes
WiFi Embedded
Yes
Auto Connectivity (with Hood)
No
SmartThings App Support
Yes
Package (WxHxD, inch)
34 1/4 X 7 1/4 X 25 1/16 inch
Cutout (WxHxD, inch)
(28 1/2 - 28 11/16) X 5 3/8 X (19 9/16 - 19 5/8)
Net Size (W x H x D) (inches)
30 X 5 3/8 X 21 1/4 inch
Shipping Weight
45.2 lbs , 20.5 kg
Net Weight (kg)
41 lbs , 18.6 kg
Loading Quantity (20/40ft)
264 / 540
Color
Black
Manufacturer Color
Black
Fuel Type
Electric
Type
Built-In
Burners/Elements
5
Power Output
• Left Front: 1,500 W
• Left Rear: Warming Center, 100 W
• Right Front: 2,000 W
• Right Rear: 1,200 W
• Center: 3,300 W (Simmer/Rapid Boil)
Burner/Element Size
• Left Front: 7"
• Right Front: 5" / 8"
• Right Rear: 6", 1
• Center: 6" / 9"
Elements
Smoothtop
Surface Features
Easy-to-Clean Glass, Ceramic Cooktop
Technologies
Wi-Fi Connectivity
Wi-Fi
Yes
Additional Information
• Flexible Cooktop with Two Dual Elements
• Blue LED Illuminated Knobs
• Front Controls
• Rapid Boil Burner
• Hot Surface Indicator Light
• Dishwasher-Safe Knobs
Information
• 240 V
• 60 Hz
• 40 A
• 195 kWh/yr
ADA Compliant
Yes
Energy Star® Certified
Energy Star® Certified
Warranty
• One (1) Year All Parts and Labor
• Five (5) Years Parts Warranty for Glass Cooktop and Radiant Heater
Class Width
30"
Weight
41.01 lb(s) / 18.6 kg
Additional Dimensions
Cooktop Cutout Dimensions: 28 1/2" x 5 1/8" x 19 9/16"
