Product Description
The SAMSUNG NX60T8511SG is a 30" smart gas slide-in range with fan convection and air fry. It adds style, convenience, and power to your kitchen with a modern, built-in look. Cook dishes quickly and evenly using the powerful heat and precise control of the 18K Burner. It also features air fry, true convection, and edge to edge grates.
- More stylish look, more ways to cook
- Powerful heat & precise simmering
- Fries food using little oil
Product Highlights
This smart slide-in gas range offers air fry, true convection, edge to edge grates, and Wi-Fi connectivity for a seamless cooking experience.
Product Information
Standard Information
-
Brand: SAMSUNG
-
Manufacturer Part Number: NX60T8511SG
Technical Specifications
-
Installation Type: Slide In
-
Number of Burner: 5 EA
-
Oven Capacity: 6.0 cu. ft.
-
Drawer Capacity: 0.9 cu.ft
-
Oven Colour: Dark Blue
-
Control Type (Oven): Glass Touch
-
Control Type (Cooktop): Knob
-
Display Type: LED
-
LED Color: Ice Blue
-
Door Type: Single Door (2 STSS Layers)
-
Soft Closing Door: No
-
Air Fry: Yes
-
Self Clean: Yes
-
Steam Clean: No
-
Wi-Fi Connection: Yes
-
Easy Cook: No
-
Healthy Cook: No
-
Favorite Cook: Access on Smart Things App
-
Keep Warm: Yes
-
Clock: Yes
-
Numeric Pad: Yes
-
Kitchen Timer: Yes
-
Child Safety Lock: Yes
-
Hidden Bake Element: No
-
Interior Light (Position): 1 Incandescent 40W(Back)
-
Light (Lamp) On/Off: Yes
-
Sound on/off: Yes
-
Setting (Clock System Option (12H/24H)): Yes
-
Delay Start: Yes
-
Sabbath Mode: Yes
-
Type: Storage
-
Cooktop Frame: Black Porcelin
-
Total Power: 58,500 BTU
-
Burner 1: 18K - Right/Front
-
Burner 2: 16K - Left/Front
-
Burner 3: 5K - Right/Rear
-
Burner 4: 9.5K - Left/Rear
-
Burner 5: 10K - Center
-
Burner Cap: 5
-
Center Oval: Yes
-
Sealed Burner: Yes
-
Grate: Edge-to-Edge
-
Convection: Convection
-
Bake (Single): 175°F (80°C) - 550°F (285°C)
-
Variable Broil (Low-High) (Single): Hi / Low
-
Convection Bake (Single): 175°F (80°C) - 550°F (285°C)
-
Convection Roast (Single): 175°F (80°C) - 550°F (285°C)
-
Bake Element: 18K
-
Broil Element: 16.5K
-
Convection Heater Element: 800W
-
Rail: Yes
-
Net Size (W x H x D) (mm): (760.4) x (920.75~939.8) x (728.66)
-
Net Weight (kg): 94.4 kg
-
Shipping Weight: 106 kg
-
Number of Rack Positions: 7
-
Air Fry Tray: Yes
-
Broil Rack: 1
-
Wire Rack (EA): 1
-
Meat Probe: No
-
Griddle: Aluminum
-
WOK grate: No
-
Anti-Tip Device: Yes
-
Smart Divider: No
-
WiFi Embedded: Yes
-
SmartThings App Support: Yes
-
Style: Slide In Gas Range
-
Brand: Samsung
-
Width: 29 7/8 Inches
-
Height: 37 Inches
-
Depth: 28 5/8 Inches
-
Energy Star: No
-
ADA Compliant: Yes
-
Nominal Width In Inches: 30"
-
Nominal Width F: 30
-
Cooking Has Continuous Grate: True
-
Cooking Oven Has Self Clean: True
-
Cooking Oven Convection: True
-
Cooking Oven Has Proof Mode: True
-
Cooking Has Storage Drawer: True
-
Cooking Oven Number Of Burners: 5
-
Cooking Gas Burner Type: Sealed
-
Appliance Oven Rack Type: Sliding
-
Has Sabbath Mode: True
-
Control Type: Illuminated Glass Touch Controls
-
Cooking System: Convection
-
Large Oven Capacity: 6.0 cu. ft.
-
Oven Cleaning Type: Self Clean
-
Powerful, Flexible Cooktop: 18K BTU Dual Ring Power Burner, Edge-to-Edge Grates
-
Cavity Type: Single
-
Configuration: Slide-In
-
Controls for Cooktop: Black Stainless Knobs
-
Controls for Oven: Illuminated Glass Touch Controls
-
Display Color: Ice Blue
-
Fuel Type: Gas
-
Oven Dimensions: 24 13/16" W x 22 7/16" H x 19 3/4" D
-
Product Dimensions: 29 15/16" W x 36 1/4" - 37" (Adjustable) H x 28 11/16" D
-
Product Weight: 208 lbs.
-
Burner - Center: 10,000 BTU, Oval
-
Burner - Left Front: 16,000 BTU
-
Burner - Left Rear: 9,500 BTU
-
Burner - Right Front: 18,000 BTU, Dual Ring Brass Power Burner
-
Burner - Right Rear: 5,000 BTU
-
Cooktop Material: Black Porcelain Enamel
-
Cooktop Type: Gas
-
Dual Power Burners: Yes
-
Matte Black Continuous Grates: Yes
-
Sealed Burners: Yes
-
Simmer Burner: Yes
-
Total Number of Burners: 5
-
Bake: Yes
-
Convection Bake: Yes
-
Convection Roast: Yes
-
Dehydrate: Yes
-
Number of Broil Racks: 1
-
Number of Wire Racks: 1
-
Proofing: Yes
-
Total Number of Racks: 2
-
Variable Broil: Yes
-
Anti-Tip Bracket: Yes
-
Filler Kit (For Slide In Range): Yes
-
LP Conversion Kit: Yes
-
Auto Oven Light: Yes
-
Power/Ratings: 120V/60Hz/20A
-
Wide View Window: Yes
-
Warranty: 1 Year Parts and Labor
-
J.D. Power Awards: Yes
