Samsung Hvac AR24TSFYBWKXCV Quantum 2.0 24K BTU Outdoor Unit (RXS24YBT)

Product Description

The SAMSUNG HVAC AR24TSFYBWKXCV is a split system outdoor unit. It operates on a voltage rating of 208 to 230 Volt AC and a frequency of 60 Hertz with a single phase. The unit features a cooling capacity of 22000 BTU/Hour and a heating capacity of 24000 BTU/Hour. Its galvanized steel enclosure has a baked-on powder-coated finish and is designed for wall mount installation.

• Features Wi-Fi capability as standard
• Easy-access to wire, pipe and drain connections via access panel on the bottom of the unit for simple installation and service
• Equipped with a hermetically sealed, inverter controlled, BLDC Rotary compressor

Product Highlights

The SAMSUNG HVAC outdoor unit is ETL (Canada and US) approved and adheres to AHRI standards. It uses R-410A refrigerant and has an airflow rating of 657 CFM (Cooling/Heating, Evaporator Fan) and 2365 CFM (Condenser Fan).

Product Information

Standard Information

• Brand: SAMSUNG HVAC
• Manufacturer Part Number: AR24TSFYBWKXCV

Technical Specifications

• Brand Name: Samsung HVAC
• Manufacturer Name: Samsung HVAC
• MPN: AR24TSFYBWKXCV
• Category: HVAC/R & Fans
• Cooling Capacity: 22000 BTU/Hour
• Cooling Coefficient: 3.07
• Current Rating: 13.5 Amp (Cooling), 18.9 Amp (Heating), 20 Amp (Minimum Circuit Ampacity), 15.2 Amp Rated Load (Compressor), 0.12/0.48 Amp Full Load (Evaporator/Condenser Fan), 30 Amp (Maximum Overcurrent Protection)
• Enclosure Finish: Baked on Powder Coated
• Enclosure Material: Galvanized Steel
• Frequency Rating: 60 Hertz
• Number Of Phases: 1
• Operating Temperature: 14 to 115 Deg F (Cooling), -5 to 75 Deg F (Heating)
• Power Rating: 27 Watt (Evaporator Fan), 125 Watt (Condenser Fan), 7.29 Kilowatt (Compressor)
• Voltage Rating: 208 to 230 Volt AC
• Approval: ETL (Canada and US)
• Heating Capacity: 24000 BTU/Hour
• Energy Efficiency: 18 SEER/10.5 EER/9 HSPF
• Refrigerant Type: R-410A
• Airflow Rating (Cooling/Heating, Evaporator Fan): 657 CFM
• Airflow Rating (Condenser Fan): 2365 CFM
• Sound Level: 56 Decibel
• Pipe Connection (Liquid): 1/4 Inch
• Pipe Connection (Gas): 5/8 Inch
• Condensate Connection (Outer Diameter): 11/16 Inch
• Compressor Type: BLDC Rotary
• Fan Type: Propeller
• Applicable Standard: AHRI
• Installation: Wall Mount
